Stab-resistant Material
  FC-1T
  FC-1S
  FC-1Y
  FC-2
  DC-2B
  DC-5BY

 Anti-stab & Bullet-resistant Material






FC-2B


Bulletproof and Stab proof fabric
Model: SZ DC-2B
Density: 270±10 g/m2
Thickness: 0.27±0.01 mm
Size:1200*2380 mm
Material: Aramid based composite material
Color: Yellow
Protection Standards: USA NIJ STD–0115.00 / UK HOSDB 2007 / BAS 2017
USA NIJ STD-0101.06


The SZ DC-2B Bulletproof and Stab proof fabric is newest scientific research achievement. Based on the FC series of our stab resistant composite materials, the DC series would be targeting to enhance the bulletproof vest’s ballistic protection and help reducing their deformation.
Now days, body armor are chasing lighter and lighter but higher steady quality, especially when people realize the BFD (back face deformation) are more serious for wearers after being shot on their bulletproof vests. Although the BPV’s not penetrated, but the deep indentation (although meet the NIJ STD as 44mm) would still bring dangerous hurt to organs.
So our SZ DC-2B was created to solve the headache problems. It would perform very good resistance to blades and spikes test according to NIJ STD–0115.00/UK HOSDB/BAS 2017, but also have high lights when stopping pistols, shotguns.

It is widely used in many fields like the following
The SZ DC-2B Bulletproof and Stab proof fabric can be used for Stab proof and bulletproof vest, Stab proof vest, Correctional armor that applied by Police officers, Military soldiers, Army officials, Law enforcement, Public Safety agencies , Safety and Security guard, Jailers, Booking Officers, civilians, etc.
When people meet cold weapons threats , such as kitchen knife, double edged knife, Sykes fighting knife, commercial ice pick, rocks, needles, etc, the SZ DC-2B based stab resistant vest would be helpful to protect them from cutting, stabbing, puncture, slashing, chopping, hacking.
When people are under the firearms threats, such as pistol, shotguns, the SZ DC-2B bulletproof and stab proof vest can stop those ammunitions such as 9mm, .44 Magnum bullets.

Features of SZ DC-2B Bulletproof and Stab proof fabric
*High strength aramid woven fabric as basic material
*Special treatments by patented process technologies
*Softness and light weight for comfortable body armor
*Customizable and upgradable ballistic constructions.



Specification of SZ DC-2B Stab-Resistant Polymer

Model:

SZ DC-2B

Density:

270±10 g/m2

Thickness:

0.27±0.01 mm

Size: 1200*2380 mm
Base material: Aramid Woven Fabric
Color: Yellow
Protection Standards:

NIJ STD–0115.00
UK HOSDB 2007 / BAS 2017
NIJ STD-0101.06




SZ DC-2B Stab proof performance

Model HOSDB KR1 HOSDB KR1+SP1 HOSDB KR2 HOSDB KR2+SP2 HOSDB KR3 HOSDB KR3+SP3

NIJ 0115.00 level 1 (Blade)

NIJ 0115.00 level 1 (Blade +Spike)

NIJ 0115.00 level 2 (Blade)

NIJ 0115.00 level 2 (Blade +Spike)

NIJ 0115.00 level 3 (Blade)

NIJ 0115.00 level 3 (Blade +Spike)

Strike Energy 24J & 36J 33J & 50J 43J & 65J

FC-2

Area density
(kg/m2)
Ply Area density
(kg/m2)
Ply Area density
(kg/m2)
Ply Area density
(kg/m2)
Ply Area density
(kg/m2)
Ply Area density
(kg/m2)
Ply

4.32

16 5.67 21 4.86 18 4.84 24
