FC-1T |
|
|
|
|
Stab resistant material
Model: SZ FC-1T
Density: 390±20 g/m2
Thickness: 0.39±0.01 mm
Size:1200*2380 mm
Material: Aramid based composite material
Color: Yellow
Protection Standards: USA NIJ STD–0115.00 / UK HOSDB 2007 / BAS 2017 |
Features of SZ FC-1T Light stab proof vest fabric
FC-1T is the most cost effective among our anti-stab materials, which owns brilliant quality stability and highlighted stab resistant performance. It can be perfectly used in anti-stab vest, stab proof and bullet resistant vest and other security products with puncture protecting purpose by its bright features of softness and toughness.
The multi-layers of FC-1T has excellent protective performance for various controlled knives, such as Standard test knife tool, Slaughtering knife, Trigonal scraper, Kitchen bone cutter, Kitchen chopper and small caliber bullets.
1.Light weight, soft excellent wearing experience;
2.5 years quality warranty (follow accurately storage and usage instructions).
3.Protect from cutting, stabbing, puncture, slashing, chopping, hacking, rocks, needles.
4.Environmental friendly, non-toxic.
5.Easy to fabricate, custom-made cut shape.
6.Grade: high grade
7.Capacity: 20000-250000 pcs per month; Prompt delivery; Factory Direct Selling;
8.ISO-9001, H.P. WHITE Test Report, USA SDS Certificate, Singapore Test Report, China Ministry of Public Security Test Report.
9.DSM appointed sole partner in Stab Proof Material development.
Specification of SZ FC-1T Stab proof fabric
Model: |
SZ FC-1T |
Density: |
390±20 g/m2 |
Thickness: |
0.39±0.01 mm |
Size: |
1200*2380 mm |
Base material: |
Aramid Woven Fabric |
Color: |
Yellow |
Protection Standards: |
USA NIJ STD–0115.00
UK HOSDB 2007/BAS 2017 |
Specification of SZ FC-1T Stab proof fabric
Model |
HOSDB KR1 |
HOSDB KR1+SP1 |
HOSDB KR2 |
HOSDB KR2+SP2 |
HOSDB KR3 |
HOSDB KR3+SP3 |
NIJ 0115.00 level 1 (Blade) |
NIJ 0115.00 level 1 (Blade +Spike) |
NIJ 0115.00 level 2 (Blade) |
NIJ 0115.00 level 2 (Blade +Spike) |
NIJ 0115.00 level 3 (Blade) |
NIJ 0115.00 level 3 (Blade +Spike) |
Strike Energy |
24J & 36J |
33J & 50J |
43J & 65J |
FC-1T |
Area density
(kg/m2) |
Ply |
Area density
(kg/m2) |
Ply |
Area density
(kg/m2) |
Ply |
Area density
(kg/m2) |
Ply |
Area density
(kg/m2) |
Ply |
Area density
(kg/m2) |
Ply |
5.46 |
14 |
6.24 |
16 |
6.63 |
17 |
7.41 |
19 |
7.41 |
19 |
8.58 |
22 |
|
