 Anti-stab & Bullet-resistant Material






DC-5BY


Bulletproof & Stab proof material
Model: SZ DC-5BY
Density: 210±10 g/m2
Thickness: 0.23±0.01 mm
Size:1200*2380 mm
Material: Aramid based composite material
Color: Yellow
Protection Standards: USA NIJ STD–0115.00 / UK HOSDB 2007 / BAS 2017
USA NIJ STD-0101.06


The SZ DC-5BY Bulletproof & Stab proof material is one of our DC series composite body armour protective materials, which are targeting to provide both bulletproof and stab proof functions.
The aramid based composite material for SZ DC-5BY is higher strength than any others similar materials. We’ve compared and tested hundreds of aramid materials and finally select the best suitable model for SZ DC-5BY. Compared to DC-2B and FC series, the DC-5BY is much lighter and thinner.
Along with new high strength materials appeared, the enhanced body armor is achieved. Different with traditional materials, the new DC-5BY can integrate the bulletproof function and the stab resistant function together. At the same time, the bulletproof & stab proof panel kept the light weight as a single functional bulletproof vest. It’s great news for those end users of police officers, military soldiers who may face weapons of both firearms, knifes, spikes, etc.
The bulletproof and stab proof combination protection levels can be mixed by each level in both NIJ 0101.06 and NIJ 0115.00/UK HOSDB/BAS2017.
A vest made of SZ DC-5BY could integrate firearms resistance and higher strike energy of cutting, stabbing, puncture, slashing, chopping, hacking, rocks, needles from cold weapons of such as knife, stick, hammer, arrow etc., and most important, no need to increase weight loading, what a perfect solution for body armor!

Features of SZ DC-5BY Bulletproof and Stab proof fabric
*High strength aramid woven fabric as basic material
*Special treatments by patented process technologies
*Softness and light weight for comfortable body armor
*Customizable and upgradable ballistic constructions.


Specification of SZ DC-5BY Stab-Resistant Polymer

Model:

SZ DC-5BY

Density:

210±10 g/m2

Thickness:

0.23±0.01 mm

Size:

1200*2380 mm

Base material: Aramid Woven Fabric
Color: Yellow
Protection Standards:

NIJ STD–0115.00
UK HOSDB 2007 / BAS 2017
NIJ STD-0101.06




SZ DC-5BY Stab proof performance

Model HOSDB KR1   HOSDB KR2   HOSDB KR3 HOSDB KR3+SP3

NIJ 0115.00 level 1 (Blade)

NIJ 0115.00 level 1 (Blade +Spike)

NIJ 0115.00 level 2 (Blade)

NIJ 0115.00 level 2 (Blade +Spike)

NIJ 0115.00 level 3 (Blade)

NIJ 0115.00 level 3 (Blade +Spike)

Strike Energy 24J & 36J 33J & 50J 43J & 65J

DC-5BY

Area density
(kg/m2)
Ply Area density
(kg/m2)
Ply Area density
(kg/m2)
Ply Area density
(kg/m2)
Ply Area density
(kg/m2)
Ply Area density
(kg/m2)
Ply

3.99

19 5.04 24 5.25 25 6.09 29
